Card Interface: 32-bit PCIe1 10/100/1000Mbps RJ45 port
Standaarden en protocollen: IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1q, 802.1p CSMA/CD, TCP/IP
Netwerkmedia: 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000Base-T: UTP category 5, 5e cable (maximum 100m)
Gevenssnelheden: 10/100/1000Mbps for Half-Duplex mode 20/200/2000Mbps for Full-Duplex mode
